GM TH-400 Deep Transmission Cooling Pan

Description

Derale’s TH400 Deep Transmission Cooling Pan #14202 uses air passing beneath the vehicle and redirects it to help lower transmission oil temperatures. With brazed, turbulator-equipped airway tubes passing through the lower section of the transmission pan for more efficient cooling, each is individually pressure tested to ensure a leak-free pan. We’ve included a much stronger magnetic drain plug and rubber/steel reusable washer, in addition to a 1/8″ NPT temperature sender bung located in the side of the pan. Finished with a durable black two-stage coating, each pan also includes neoprene gasket and 1/8″ NPT temperature sender plug.

Specifications

• Pan Dimensions: 16 1/2″ Length x 12 13/16″ Width x 4 1/2″ Height
  Drain plug adds 1/4″ to height
• Tube depth: 3-1/16″
• Extra capacity from Std. OE pan: 3 qts. 8 oz.
• Extra capacity from Deep OE pan: 1 qt. 3 oz.
• Temp bung size: 1/8″ NPT
• Drain plug size 1/2″-20
• Replacement drain plug Derale 14000

Features

• Heavy gauge stamped steel construction
• Two stage heat dissipating black finish
• 1/8″ NPT temperature sender port
• Reduces fluid temperatures up to 50°F
• Increases fluid capacity by up to 3 qts. 8 oz.
• Patented turbulator cooling tubes add heat transfer capability
• Magnetic drain plug with increased magnetic strength and rubber/steel washer
• Use Derale 14002 filter pickup tube if needed


  ---

  Part No. 14202 Transmission Cooling Pan
